100mw 300mw production line of solar panel for factory
Product Description
Incoming Material Inspection: Raw materials (wafers, glass, encapsulant, backsheet, aluminum frames, junction boxes, etc.) are inspected for quality and conformity to specifications.
Cell Processing (if applicable): If the factory starts with bare wafers (rather than pre-processed cells), this stage involves texturing, diffusion, anti-reflective coating, and metallization to create the solar cells. This is a highly specialized area, often done by separate companies. Most panel assembly lines start with pre-made cells. Cell Testing and Sorting: Individual solar cells are tested for electrical performance (voltage, current, efficiency) and sorted into bins based on their characteristics. Tabbing and Stringing: Cells are interconnected into strings using thin, conductive ribbons (tabbing ribbon). String Inspection: Strings are inspected for defects (misaligned cells, broken ribbons, soldering issues). This can be manual or automated (using a 90-degree flip machine, as discussed earlier). Layup: Strings are arranged on a sheet of glass (with encapsulant) in the desired configuration to form the panel matrix. Busbar Welding: Busbars (wider conductive ribbons) are welded to the ends of the strings to connect them electrically and create the panel's main current collectors. Pre-Lamination Inspection: The assembled matrix is inspected again before lamination. Lamination: The entire assembly (glass, encapsulant, cell matrix, backsheet) is heated and pressed under vacuum to bond the layers together and create a sealed, weatherproof module. Edge Trimming: Excess encapsulant and backsheet material are trimmed from the edges of the laminated module. Framing: An aluminum frame is attached to the perimeter of the laminated module for structural support and ease of mounting. Junction Box Attachment: The junction box (containing bypass diodes and output connectors) is attached to the back of the panel. Final Testing: The finished panel undergoes a series of tests: Sun Simulation: Measures the panel's power output under standard test conditions (STC). Electroluminescence (EL) Testing: Detects microcracks, cell defects, and other hidden flaws. Wet Leakage Current Test: Measures the resistance in wet weather. Insulation Test: Measures insulation quality. Grounding Test: Measures grounding quality.
Sorting and Packaging: Panels are sorted based on their power output and packaged for shipment.
| capacity | 100MW | 300MW | 500MW |
| rhythm | 30S | 22S | 22S |
| Number of workers | 15-20 | 20-25 | 20-27 |
| Factory size | 3000m² | 5000m² | 7500m² |
| pv powers | 500w-730w | 500w-730w | 500w-730w |
Edobo Company specializes in producing solar panel production lines. With 15 years of research and development experience, we have developed advanced technologies and processes to ensure that our production line achieves the highest quality and efficiency. Our expert team is committed to providing innovative solutions for the solar energy industry, helping our customers achieve production targets of 100MW/300MW/500MW, and creating huge profits for them.
1.Engineers stationed on the project site have been leaving the team for up to six months, training production staff and management team
2.24-hour after-sales service hotline, with expert one-on-one service within 2-4 hours, to promptly handle customer issues
3.Regularly follow up, collect customer on-site usage information and feedback, analyze issues and provide technical support
4.Free installation guidance and operation training provided
5.software upgrade services
6.life service
- Model NO.:
- solar panel line
- After-sales Service:
- Engineers Available to Service Machinery Overseas
- Major Equipment:
- Glass Loading Machine, Stringer, Laminator, Curing
- Power Supply:
- 380V
- Rhythm:
- 22s-30s
- Factory Size:
- 3000m²-7000m²
- PV Powers:
- 500W-730W
- Transport Package:
- Container
- Specification:
- 500MW/300MW/100MW
- Trademark:
- EDOBO
- Origin:
- China
